CNC Gantry plasma cutter with fine spray gun
CNC gantry plasma Cutter With Fine Spray Gun water jet
| Model: | 3060/4080 |
| Category: |
CNC Plasma Gantry Cutter With Fine Spray Gun+flame attached |
| cutting mode | Plasma+flame(oxyfuel gas) |
| Brand: | allwin cnc |
| Rating: | 4.7 /5 based on 61 votes |
| Standard Price: | $5200.00 / Set |
| Price Range: | $4800.00 to $9200.00 / Set According to Configurations |
| Supply Ability: | 30 Sets / Month In stock! From – Jinan allwin cnc machinery co.,ltd |
| Payment Terms: | T/T,L/C,paypal,Westunion |
Water jet plasma cutter with fine gun
details for CNC Plasma Gantry Cutting machine With Fine Spray gun
High-precision CNC plasma gantry cutting machine is so called water jet plasma cutter
suitable for large-format and medium and heavy metal sheet cutting.
This kind of high-precision water jet plasma cutter has high various configurations,
large effective working area, thick plates for cutting,
and it is recommended to choose this type of cutting machine for cutting plates below 50 mm;
this high-precision H-beam metal plasma cutting equipment has excellent performance,
The cutting surface has high verticality. In the cutting process, you can choose mixed gas cutting and water spray fine cutting torch and other processes; the cutting area of this high-precision plasma metal cutting machine can be customized;
the operating speed can reach 24 meters per minute,
and the cutting speed can reach 12 meters per minute.
Flame cutting is optional to meet the company’s thick plate cutting requirements.
The CNC gantry plasma cutter equiped with water spray gun
adopts a square tube welding structure, which has the characteristics of good rigidity with high precision parts,
For the welding parts of the machine, stress relief is adopted to prevent structural deformation;
longitudinal and lateral transmission: precision rack (7-level accuracy) transmission is adopted.
The horizontal guide rail adopts imported linear guide rail, and the longitudinal guide rail adopts precision-machined special steel rail, which ensures the smooth running, high precision, durability, cleanness and beauty of the cutting machine; the speed reduction adopts the planetary gear reducer imported from Germany, which can ensure the accuracy and balance of the movement Longitudinal drive frame (end frame):both ends are equipped with horizontal guide wheels, which can drive the compression degree of the eccentric wheel at the bottom of the frame to guide the movement of the whole machine; adopt servo drive technology to make the whole machine run smoothly, and the speed can be fast or slow , The acceleration time is short;
Fine Spray torch
Plasma control system
Height control THC FL1621
Plasma fine torch 300A
high-precision plasma cutting machine Applications
Cutting carbon steel
Cutting workpiece
cutting stainless steel
why water jet plasma cutting machine water spraying gun?
Advantages of water jet cnc plasma gantry cutting machine
1 Better cutting effect, high cutting accuracy, higher verticality of the cut surface of the workpiece, no slag or less slag;
2 Reduce environmental pollution. Greatly reduce the smoke and dust emission, avoid the exposure of strong light, and minimize the damage to the human body;
3 The professionally cnc gantry plasma cutter tuned cutting torch cooling system is equipped with a large flow, high-lift water pump and a high-power heat dissipation structure, which effectively prolongs the service life of the cutting torch consumables;
4 The design of multiple gas input interfaces adapts to multiple gas cutting processes and realizes high-quality cutting of various metal materials;
5 The plasma cutting machine is equipped with an initial positioning device and an automatic height adjustment system. During the cutting process, it has 360 anti-collision equipment.
6 The longitudinal and transverse guide rails are driven by linear guide rails, which makes the machine run more smoothly.
7.This CNC gantry plasma cutter with rotary axis could cut metal sheet with bigger metal pipe together.its control system support 2 axis and 4 axis together.professional nest software startcam or fastcam avoid material waste.
| 1 | Model | ALLWIN-6012 | ALLWIN-4080 | |
| 2 | Power Source | AC220±10% 50/60Hz 220W | ||
| 3 | Cutting Mode | O2/C3H8 Or C2H2 | ||
| 4 | EffectiveCutting Range(Mm) | 4000mmx10000mm | 3000mmx6000mm | |
| 5 | Plasma Cutting Gas | N2,O2,CompressedAir | ||
| 6 | Flame Cutting Gas | Oxygen+Propane Or Acetylene | ||
| 7 | Beam Width RaiLength(M) | 6m*12m | 4m*8m | |
| 8 | Speed(Mm/Min) | 50-10000mm/Min | ||
| 9 | Flame Cutting Thickness(Mm) | 5-150 (Oxygen + Acetylene Or Propane) | ||
| 10 | Plasma Cutting Thickness(Mm) | 2-20mm | ||
| 11 | touch sensor | ±0.2mm/M | ||
| 12 | cutting Torch | Flame torch Plasma torch | ||
| 13 | Cutting System | FANGLING F2300B THC F1621 | ||
| 14 | Gas Pressure(Mpa) | Max.0.1 | ||
| 15 | Oxygen Pressure(Mpa) | Max.0.7 | ||
| 16 | Type Of Gas | C3H8 C2H2 | ||
| 17 | Emergency Stop | Yes | ||
| 18 | nest software | FASTCAM | ||
| 19 | Motor | panasonic servo | ||
| 20 | Plasma Power | 200A,300A,400A for option | ||
| 21 | ARC method | Untouched Arc Striking | ||
| 22 | Processing Materials | Iron,Tianium plates Steel Aluminum Sheets, Galvanized Sheets | ||
What is CNC Plasma gantry cutter with fine spray gun?why use water jet plasma cutter?
water jet plasma cutting machine is equipped with a fine water spray cutting torch.
This Plasma cutter is different from other type of regular plasma torch,this fine cutting gun greatly reduces the smoke and light pollution during the cutting process, which is harmful to the human body.Fine spray cutting torch keep the damage to minimum;
with help of spraying water during cutting process to make this plasma cutter cuts very clean without slag.
In terms of cutting performance, the fine water spray gun is superior to other plasma cutting guns, which is mainly reflected in the smooth and flat cut surface of the cut work piece, higher cut perpendicularity, less slag or no slag;
The cutting effect of a plasma cutting machine with a high-profile version is comparable to that of a laser cutting machine with a low-profile version.
with workshop require very higher for working environment,It is widely used in metal cutting companies that are not afraid of water,
Furthermore,more and more people use this fine water spraying torch plus high precision CNC plasma machine put into metal fabrication industries to be fiber laser cutting machine instead.
Cutting Capacity of plasma geneartor
| China Huayuan Power | USA Hypertherm Power | ||
| Power supply | Cutting thickness | Power supply | Cutting thickness |
| 63A | 8mm | 45A | 8mm |
| 100A | 15mm | 65A | 10mm |
| 120A | 20mm | 85A | 12mm |
| 160A | 30mm | 105A | 18mm |
| 200A | 40mm | 125A | 25mm |
| 200A | 30mm | ||
Related China metal cnc plasma cutter
package and delivery for our cnc plasma cutter
All of our export machinery and equipment adopt standard plywood boxes after high temperature and high pressure treatment. The boxes meet the inspection standards of the United States and the European Union; the transportation method can be transported by plane, ship, or train according to customer requirements.
We have our own long-term cooperation transportation company, which will give us more favorable prices and feasible suggestions in transportation prices, which will minimize the customer’s freight expenses, and there will never be overcharges.
we here provide you one-stop solution for metal industries cnc machine at affordable price
